CV-18 Fujian/003 CATOBAR carrier thread

[jimmyjames30x30]

https://twitter.com/i/web/status/1397526628452823041

How recent is this?



[KampfAlwin]

How recent is this?

I think maybe a week+ since we know the port overhang modules have been filled with more modules that are now level with the flight deck.



[Deino]

How recent is this?

Allegedly from 23. May



[Mulong]

The new one... What's this?



[Daniel707]

The new one... What's this?View attachment 72605



[Intrepid]

Interesting the pits to work on the sonar of Type 55.



[Twix101]

View attachment 72607View attachment 72608

Looks like we can see the funnels right after the aft elevator and possibly the island location as well.



[Intrepid]

Looks like we can see the funnels right after the aft elevator and possibly the island location as well.

If we can really see the deck openings for the chimneys - I'm not sure - then more where the red arrows point. Maybe also where the blue arrows point.

With the chimneys in a rectangle, it would be a wide, short island, not a long narrow one.



[SINCHIKI]

If we can really see the deck openings for the chimneys - I'm not sure - then more where the red arrows point. Maybe also where the blue arrows point.

With the chimneys in a rectangle, it would be a wide, short island, not a long narrow one.

View attachment 72612

Different angles, the width looks a bit strange, not sure if the photo is stretched.



[kickars]

Different angles, the width looks a bit strange, not sure if the photo is stretched.
View attachment 72614

Don’t think the photo has been stretched as the Chinese characters seem to be just right. The reason it looks wider than one might think is purely because of the perspective.
